Design Wavelength

633nm

Coating

BBAR (450-750nm)

Wavelength Range

450nm-750nm

Entrance Aperture

2mm

Exit Aperture

27mm

Transmitted Wavefront,

P-V

＜λ/4@633nm for

Input Beam≤1mm

Mounting Threads

C-Mount

Substrate

Optical Glass

Housing Diameter

50mm

Angle of Incidence

0°

Focus Range

1.2m-∞

Coating Specification

Rabs<0.4%@630-670nm

Ravg<0.6%@450-750nm

Divergence Adjustment

Non-Rotating Optics
